| One-in-one-out switch signal isolation transmitter |
| Download Name: One-in-one-out switch signal isolation transmitter |
 |
| Model: JSD TAK-1001D |
| Date Added: 2025-1-3 |
| Clicks: 155 |
 |
| Download Instructions |
|
One-In-One-Out Switch Signal Isolation Transmitter
The JSD TAK-1001D series switch signal isolation transmitter, developed by Jieshengda Technology, is a compact instrumentation device that isolates, converts, transmits switch signals and transmits them to industrial sites as standard analog voltage and current signals without distortion.
This product is mainly used in scenarios where switch signals control industrial on-site equipment and can also be applied as a DA converter. It has built-in multiple groups of low-power high-isolation DC-DC power supplies and a set of high-isolation photoelectric coupling circuits. With internal SMD (Surface Mount Device) technology and new isolation technology, the creepage distance enables mutual isolation between the product's input, output, and working power supply, with an isolation voltage of up to 3000VDC.
It can effectively suppress strong electrical and strong magnetic field interference in the complex on-site environment of industrial control systems, providing protection for industrial automation control systems.
|
|
|
|
|
